razor barbed wire with accessories

Material: Electro galvanized iron wire, hotdip galvanized iron wire and PVC coated iron wire
Razor distance: 3 - 6 inches
Feature:Galvanized razorwire offers a great protection against corrosion and oxidation caused by the atmosphere. Its high resistance allows greater spacing between the fencing posts.
Packing:In coils. 12-25kg small roll 5 kg or big roll 25 kg,etc. 100 m,250 m etc
Application:Razor barbed wire is a product recommended for the construction of strong and lasting fencings. It is extremely adapted to control heavy and wild animals.Razor barbed wire can be widely used as accessories for woven wires fences to form a fencing system or security system. It is called razor barbed wire fences or barbed obstacles when it is used simply by itself along the wall or the building to give a kind of protection.

Reference Type Number	Thickness	Wire Dia.	Barb Length	Barb width	Barb spacing
BTO-10	0.5±0.05	2.5±0.1	10±1	13±1	25±1
BTO-12	0.5±0.05	2.5±0.1	12±1	15±1	25±1
BTO-18	0.5±0.05	2.5±0.1	18±1	15±1	35±1
BTO-22	0.5±0.05	2.5±0.1	22±1	15±1	36±1
BTO-28	0.5±0.05	2.5	28	15	46±1
BTO-30	0.5±0.05	2.5	30	18	46±1
CBT-65	0.6±0.05	2.5±0.1	65±1	21±1	101±2

Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
450 mm	33	8M	CBT-65	Single Coil
500 mm	41	10 M	CBT-65	Single Coil
700 mm	41	10 M	CBT-65	Single Coil
960 mm	53	13 M	CBT-65	Single Coil
500 mm	102	16 M	BTO-10,15,22	Cross type
600 mm	86	14 M	BTO-10,15,22	Cross type
700 mm	72	12 M	BTO-10,15,22	Cross type
800 mm	64	10 M	BTO-10,15,22	Cross type
960 mm	52	9 M	BTO-10,15,22	Cross type
