MILITARY CONCERTINA RAZOR WIRE

Military Razor wire is widely used in prisons, border posts, detention centers,government building or other security facilities.Also used for division of railway, highway, agricultural fencing, etc.

It is relatively inexpensive, but viciously effective. Concertina razor Wire around the perimeter is enough to deter any wouldbe vandal, robber or saboteur. Razor Wire is made of a corrosion resistant galvanized steel cutting ribbon wrapped around a core of galvanized spring steel wire. It's impossible to cut without highly specialized tools, and even then it's a slow, dangerous job. Concertina Razor Wire is a long lasting and very effective barrier, known and trusted by security professionals.

Welded razor wire mesh and concertina razor wire coil can also be combined with each other, and such an effective combination can prevent the theft of all illegal elements. In military, frontier or some well-organized places are heavily used by military soldiers.
Straight blade razor wire no buckle, the outer packaging is the same as the general barbed wire, it can be pulled into a straight line after opening, and it is also widely used in military .

Spiral razor wire is a wide range of razor barbed wire. It is simple to install and has good anti-theft effect. More than 80% of the market is this kind of barbed wire. It is widely used in border defense lines, general factories and residential walls, the diameter can be selected according to customer needs. generally, the diameters of 800 mm and 900 mm are used, and the civil will choose the diameter of 500 mm.

Razor wire has various types according to the blade specification, such as BTO-12, BTO-18, CBT-65. The BTO refers to barbed tape obstacle. And the 12, 18 or 65 refers to the barb length, barb length is the distance from in the middle of the blade tape to the next to the blade tape. The barbed length is longer, the razor wire is much sharper and more safe.

Specification

Material: galvanized steel wire or stainless steel wire

Type: razor wire Coil

Razor thickness: 0.5mm-0.6mm +/-0.05mm

Razor Type: cross razor

Diameter: 450mm-960mm

Barbed distance: 7.5-15cm

BTO-22 CBT-65 Galvanized Concertina Razor Barbed Wire

Type	Wire Gauge (SWG)		Barb Spacing (mm)	Barbed Length (mm)
Electric Galvanized & Hot-dip Galvanized	10# x 12#		75-150	15-30
	12# x 12#
	12# x 14#
	14# x 14#
	14# x 16#
	16# x 16#
	16# x 18#
PVC coated	before coating	after coating	75-150	15-30
	1.0mm -3.5mm	1.4mm -4.0mm
	SWG11#-20#	SWG8#-17#
	PVC coating thickness: 0.4mm -0.6mm ; different coating colors are available.

Hot Dipped Galvanized Concertina Razor Barbed Wire Mesh for Protection BWG 12 / BWG 18

Model Number: Barbed wire - 1
Material: Iron Wire
Surface Treatment: galvanized
Type: Barbed Wire Coil
Razor Type: Cross Razor
Wire gague: bwg12*14, bwg14*14, bwg16*16
Strand: Single, Double, General
Wire diameter: 1.6mm-2.8mm(BWG12-BWG16)
Packing: 50kg/coil
Length: 50m 100m
Surface: Hot Galvanized+PVC+Electro Galvanized

Chain Link Fence Systems Concertina Hot Dipped Galvanized Razor Barbed Wire

Concertina Hot Dipped Galvanized Razor Barbed Wire

Barbed Tape Wire Specification Of Razor Wire
Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
450mm	33	7-8M	CBT-60.65	Single coil
500mm	56	12-13M	CBT-60.65	Single coil
700mm	56	13-14M	CBT-60.65	Single coil
960mm	56	14-15M	CBT-60.65	Single coil
450mm	56	8-9M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
500mm	56	9-10M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
600mm	56	10-11M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
600mm	56	8-10M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
700mm	56	10-12M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
800mm	56	11-13M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
900mm	56	12-14M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
960mm	56	13-15M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
980mm	56	14-16M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross ty

50cm diameter cross concertina razor wire BTO-22 5kgs/coil

It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets.
